Product Description
Filling pump to the upper part of the air pump, the compressed air into the air distribution chamber through the slider, slide valve gas reversing device, so that the air entering the cylinder piston upper or lower end of the piston, piston reaches within a certain distance automatic reversing the intake and exhaust, so as to make reciprocating movement. Germany CAONEY coney butter machine injection pump of the lower part of the plunger pump, the source of its power, in the air pump, by the connecting rod is connected, and the air pump for synchronous reciprocating motion. There is two one-way valve is a set of in feed lifting rod said is a four-way valve and a feeding rod axial sealing plunger pump; another on the end of the plunger rod arrangement oil outlet of a nylon piston and sealed with cone and discharging valve seat linear, their work is oil pump synchronous commute to work. When the plunger rod to sports, close the nylon plunger, provided material rod connected to the lifting plate will be oil to oil pushed four-way valve to open into the pump; when the piston rod moves downwards, four-way valve shut down, pump oil plunger rod extrusion open nylon piston valve again oil discharge, such oil injection pump as long as the reciprocating action, can make the oil produce high pressure oil discharge effect.
注油泵上端部份为空气泵，由压缩空气进入配气室通过滑块、滑阀等气流换向装置，使空气进入气缸活塞上端或活塞下端，达到活塞在一定行程内自动换向进气和排气，从而作往复的运动。德国CAONEY科尼黄油机注油泵的下端部份是柱塞泵，它的动力来源于空气泵，二者由连接杆联接，与空气泵作同步的往复运动。柱塞泵内有二个单向阀一个是套在提料杆上称为四脚阀瓣与提料杆做轴向密封；另一个在柱塞杆端部排油口的一个尼龙活塞，用锥面与排料阀座线性密封，它们的工作是与注油泵同步往返工作。当柱塞杆向上运动时，尼龙柱塞关闭，提料杆连接着提料板将油料向上提，油料就推开四脚阀向上开启进入泵内；当柱塞杆向下运动时，四脚阀向下关闭，泵内油料受柱塞杆挤压打开尼龙活塞阀门再次排油，这样注油泵只要上下往复行动，就能使油料产生高压力得到排油作用。
摊铺机
Q: what is the principle of pneumatic oil pump work?
A butter pump is a device for the application of butter in life. The use of this equipment is very good for us to play a helping role. Butter pump in life is a pneumatic butter pump and electric pump of the sub, then for the gas pump this device, it is in life, how to work it?!
Pneumatic grease pump through the compressed air to drive the reciprocating motion of the piston, utilizes the difference of piston is arranged at the lower end of the area, and get high pressure fluid output, output liquid pressure is determined at both ends of the piston area ratio of driving gas pressure. Both ends of the piston area ratio is defined as the ratio of the pump, and marked in the pump model. Fluid with different pressure output can be obtained by adjusting the working pressure. Oil absorption and oil pressure by the plunger in the plunger set in the reciprocating movement to complete. When the plunger is in the lower position, the plunger sleeve on the two oil holes are opened, plunger sleeve and the inner cavity of a pump body oil channel is communicated, fuel quickly filled with oil chamber.
When the cam is pushed onto the roller of the roller body, the plunger is raised. From the beginning of the plunger movement up to the oil hole is blocked by the upper end of the plunger. During this period of time, due to the movement of the plunger, the fuel is squeezed out from the oil chamber and flows into the oil channel. So this process is called pre stroke. When the plunger will block the oil hole, then began to press the oil process. Plunger up, oil chamber oil pressure increased sharply. When the pressure exceeds the spring force and the upper oil pressure of the oil valve, the oil valve is opened on the top, and the fuel oil pressure of the oil pipe is sent to the fuel injector.
问：气动黄油泵工作的原理是什么?
答：黄油泵是生活中为机械设备涂抹黄油的一种设备。这种设备的使用是能够很好的对我们起到帮助作用的。黄油泵在生活中是有气动黄油泵和电动黄油泵之分的，那么对于气动黄油泵这种设备来说，其在生活中是怎样进行工作的呢?下面我们就一起来看看吧!
气动黄油泵通过压缩空气带动活塞往复运动，利用活塞上下端面积差，而获得高压流体输出，液体输出压力取决于活塞两端面积比及驱动气体的压力。活塞两端面积比定义为泵的比率，并标示在泵的型号中。通过调节工作气压可获得不同压力输出的流体。吸油和压油的时候由柱塞在柱塞套内的往复运动来完成。当柱塞位于下部位置时，柱塞套上的两个油孔被打开，柱塞套内腔与泵体内的油道相通，燃油迅速注满油室。
凸轮顶到滚轮体的滚轮上时，柱塞便升起。从柱塞开始间向上运动到油孔被柱塞上端面挡住前为止。在这一段时间内，由于柱塞的运动，燃油从油室被挤出，流向油道。所以这段升程称为预行程。当柱塞将油孔挡住时，便开始压油过程。柱塞上行，油室内油压急剧升高。当压力超过出油阀的弹簧弹力和上部油压时，就顶开出油阀，燃油压入油管送至喷油器。
