Description:

Product Description

The working principle of the paving machine: the hammer is driven by the eccentric shaft to realize the up and down movement, and thus the material under the pressing plate is pressed. In order to obtain a higher degree of pre compaction, the compaction should be based on the specific layer thickness and spreading speed. In order to be able to set the hammer, two parameters must be carefully chosen: eccentric shaft speed and ram stroke. The eccentric shaft speed of the driving hammer can be continuously changed between 300 and 1800rpm, and the speed control can be easily realized by the hand control panel. Expert advice: the spread of wear layer in the use of 300 to 800rpm hammer speed.

摊铺机夯锤的工作原理：夯锤由偏心轴驱动，实现上下运动，从而压紧熨平板下方的材料。为了获得更高的预压实度，应该根据特定的层厚和摊铺速度正确的设置夯锤。为了能够理想地设置夯锤，要谨慎选择两个参数：偏心轴速度和夯锤行程。驱动夯锤的偏心轴速度可在 300 至 1,800rpm之间无级变化，通过机手控制面板，可以轻松实现速度控制。专家建议：在摊铺磨耗层时采用 300 至 800rpm 的夯锤速度。

Packaging & Shipping

1. MOQ:1pcs

2. Delivery terms:by sea/ by air

3. Delivery times:7-15 Days

4. Payment terms:FOB/EXW/CIF

Our Services

1. Warranty

2. After-sales service

3. Quality certification

4. Customized service

5. Sample service
