Causes of derailment of paver chain rail

During the construction of the paver, problems often occur on the track, such as derailment of the track, but do you know the reason for derailment?

The cause of the track analysis failure may be that the tension cylinder is not fully ejected, or the guide wheel flange is abnormally worn.

When the paver was first used, the track tension was not very appropriate. The right track derailed when the turning radius was small, but the tension cylinder was not adjusted timely.

After the paver has been used for a long time, the oil cylinder always stops at one position, which makes it difficult to tighten and loosen (the tensioning oil cylinder is retracted only when the paver is repaired with a jack), so that the driver may force the installation of tracks.

In this process, the externally inclined track will pull the installation side plate of the guide wheel outward, making it tilt outward, which is more likely to cause derailment of the track.

Moderate adjustment of the tensioning cylinder can reduce the derailment of the track. After the derailment of the track, try to retract the tensioning cylinder to the inner side, and then install the track.
